poly enameled Aluminium winding wire

Product Description

With a vision to be a pioneer in our domain, we are emerging as one of the leading manufacturers and suppliers of Poly Enameled Aluminium Winding Wire. The mechanical, electrical and chemical characteristics of this wire are different from those of copper wire because of the inherent differences in the conductor materials. We manufacture this wire using high quality aluminum, procured from trusted vendors. This wire is ideal for using in all kinds of transformers, motors and generators. Poly Enameled Aluminium Winding Wire has high temperature-resistance, cold-resistance and radiation-resistance. It is available in different sizes and grades as per client's requirements.

Further Details:

Aluminium competes closely with copper formost industrial and household applications. With remarkable electricalproperties and advancement in manufacturing process  it allows to capitalise on the significantdifference in the price of both the metals. With all these bundled benefits, IMIDE’s enamelled aluminium wire can besuccessfully used to replace the copper enamelled wires, where needed.

We make it available in different sizes, typesand grades of enamels to ensure best results for all special fields ofapplication.

(Please make sure all the categories arecovered in one or the other product listing)

Categories:

   1.Polyester Enameled Aluminum Wire

2.                 3.                 4.                 5.                  Winding Wires

Diameter: 0.081 mm to 4.064 mm

Conductor Type: Solid

Conductor Material : Aluminium

Packaging Type: Cylindrical and Taper spoolsin multi ply boxes

Place of Origin: Delhi

Coating: Modified Polyester

Elongation : 15-48% (gauge dependent)

Material grade: Pure electrical transmissiongrade

Insulation material : Enamelled

Condition : New

Standard : above ISI specifications

Working temperature: 155 / 180 / 200 / 220

Colour: Golden - reddish brown

Temperature class : F / H / Dual Coats

Is it rust proof : RUST POOF

Aluminium Volume %: 99.99

Packaging :Automised machine Packaging

Is it CEcertified:  CE certified

Alloy Or Not: NOT

Shape: ROUND WIRE

Surface: FREE FROM SPOTS

DEFECT RATE: 0.1%

Tolerance: 0.004mm
